ASP - S91A R/C Engine image

ASP - S91A R/C Engine

Manufacturer: ASP Engines Product Code: ASP91A


ASP - S91A R/C Engine



price
$340.00

 Dispatch
10 - 21 Business Days

ASP - S91A R/C Engine

Displacement:14.95cc
Stroke: 24.8mm
Bore: 27.7mm
RPM range: 2,000-17,000(r.p.m)
Output: 2.10/16,000(kw/r.p.m)
Weight: 720g
Suitable Prop: 13x8-14x8

MOUNTING DIMENSIONS(specs are according to real measure, may slightly different to official figures):
Distance between mounting holes on same side: 25mm
Distance between mounting holes on opposite side: 52.5
Length from back of crankcase to end of output shaft: 129mm
Length output shaft: 36mm (outside)
Diameter of output shaft: 7.9mm
Height from bottom of crankcase to top of cylinder head: 102mm
Width at mounting flanges: 61mm
Width at crankcase: 42mm
Distance of muffler mounting bolts(center to center): 42mm
